Model:900x2000
Features
1.The Flexo folder gluer machine's roller-style lead edge feeder for accurate feeding, durability, and ease of use. For accurate and stable work, the primary transmission gear is made of premium alloyed steel that has been chamfered and ground. The bearings are from the well-known brands HRB and NSK.
2. And Key-free rings ensure accurate registration through highly precise transmission.
3.Quick and easy manual gap micro-adjustment. Each gearbox stores oil for ongoing spray lubrication.
System of electrical auto control
4.Auto sheet counting, speed indication, skip feeding, fault warning, PLC control, etc. The primary electrical components are made by Siemens, Omron, or Schneider.
5.Flexo folder gluer machine including main machine start protection: no lock, no run, for wrong operation. 6.Motorized walk: pneumatic lock, motorized open and closing. To protect the maintenance technicians, a motorized walk is equipped with a continuous alarm. To prevent the printing unit from moving, an auto braking system is used.
7.Emergency stop: each unit has an internal emergency stop that prevents the machine from moving while maintenance is being performed.
Machine Details
|
Paper size |
90x200cm |
|
Design speed: |
400pcs/min. |
|
Max. speed： |
350pcs/min.(by sheet size and quality) |
|
Max.working size： |
300x400 |
|
Min. Paper size: |
170X420mmmm |
|
Skip feeding size： |
1200mm x 2000mm |
|
Max.printer area： |
900x1950mm |
|
Cliché thickness： |
1-7.2mm |
|
Max. paper thickness |
10mm |
|
Die cutting accuracy |
±1.5mm |
|
Printing registration(medium speed): |
±0.5mm |
Features of printing unit
Satellite gear wheel structure, PLC control, digital display, 360-degree circumferential adjustment, stable start, and correction positioning are all used in printing phase adjustment.
A robust chrome-grinded printing cylinder with center and cross lines for easy cliché registration, proper placement, and cliché fixation and adhering.
For high-speed running, balance therapy and steady running.
The printing cliché can be quickly and easily fixed.
A fast cliché changing method to expedite order renewal.
The printing cylinder moves 10 mm to the left and right.
The printing cylinder's zero position feature allows for rapid cliché adjustment and positioning for frequent carton specification changes. Foot stepping mechanism for fixing and disassembling clichés. phase micro-adjustment.
Auto Folder gluer unit
The gluing machine uses premium steel welding that has been meticulously processed and assembled. The folding department has an adjustable line pressing wheel, which improves the smoothness of folding cartons and the accuracy and beauty of the glue.
The printing machine's die cutting or slotting unit is linked to the glue machine, and the electrical control system communicates with the printing machine.The glue machine runs concurrently with the printing machine.They are a single system.
Advatages and Benefits
If customer buying Flexo folder gluer machine is a big strategic decision for a manufacturer of corrugated packaging. This technology is a comprehensive solution that transforms your factory floor and your business capabilities, in contrast to isolated equipment. The benefits of this purchase go much beyond just getting a new computer; it's an investment in the future productivity, profitability, and competitiveness of your business.
Here are the primary advantages of buying an inline printer-slotter-die cutter with gluer:
Increased ROI (return on investment)
Significantly Lower Cost Per Box: You can eliminate work-in-progress inventories, cut labor expenses, and limit material waste by merging various processes. Your profit margin on each and every box manufactured is immediately increased as a result.
Rapid Throughput: You may increase your production capacity without requiring more floor space or numerous operators thanks to these machines' incredible speed, which enables you to complete huge orders more quickly. Increased revenue potential is directly correlated with this higher volume capabilities.
Energy and Overhead Savings: Running one high-efficiency machine reduces your overall operating overhead because it uses a lot less energy and resources than running three or four different machines.
